FEATURE
- ECU free solution design
- Front corner detection
- Back parking assist
- Bumper hole free installation
Configuration | Dual radar sensor |
Active Condition | Switch ON |
FOV Per Sensor | HFOV 144゜ |
Maximum Detection Range | 5m |
Alert Range | <=0.6m |
Peripheral Interfaces | Stand alone and buzzer |
Power Consumption | 200 mA @ 12 VDC (maximum) |
Voltage Range | 8 V to 18 V |
Operating Temperature | -40°C~85°C |
Water Proofing | IPX7 |
Dimensions Per Sensor | 64.81 x 47.48 x 21.69 mm |
Weight Per Sensor | 16 g |
